No MOQ 12864 Graphic LCD Display in Stock

There are thousands version of 128×64 dots LCD Display in Haresan`s factory since 2006, Below is our on-hand inventory  Model HEM12864-164 for sales without MOQ limited

HEM12864-164

1.FUNCTIONS & FEATURES
1-1. Format : 128X64 Dots
1-2. LCD mode : STN, GRAY, TRANSFLECTIVE, POSITIVE.
1-3. Viewing direction : 6 o’clock
1-4. Drive mode : 1/64 Duty , 1/7 Bias
1-5. Operating voltage/current(Vdd/Idd) : 3.0V
1-6. LCD driving voltage (VOP) : 8.9V
1-7. Operating temperature : -20℃~70℃
1-8. Storage temperature : -30℃~80℃
1-9. Backlight : White side LED (Vf=3.0V,If=15*3=45mA)
1-10. Drive IC : ST7567(COG)

2.MECHANICAL SPECIFICATIONS
2-1. Module size : 54.6mm(L)*42.2mm(W)*6.0mm(H)
2-2. Viewing area : 50.6mm(L)*31.0mm(W)
2-3. Active area : 46.56mm(L)*27.68mm(W)
2-4. Dot pitch : 0.364mm(L)*0.433mm(W)
2-5. Dot size : 0.334mm(L)*0.403mm(W)
2-6. Assemblage : COG + BL



Welcome to contact our sales know more in stock, Free Samples limite QTY  available.

HEM12864 LCD Display
