0.96″PMOLED OHEM12864-13B

Short Description:

Product Details Model Number:OHEM12864-13B Brand Name:HEM Origin:China (mainland) Key Specifications/Special Features: 0.96″ blue white 128×64 PMOLED display         ●0.96″ 128 x 64 pixel         ●Interface: SPI, I2C         ●3.3-5V logic and power         ●Drive IC: SSD1306         ●View area: 23.744mm x 12.864mm Size: 0.96 inch Resolution: 128 x64 Driving voltage: 2.8-3.3 V (with automatic booster) Driver IC: SSD1306 Support interface: 8 bits parallel, 3/4 line SPI,...


  • FOB Price: US $0.5 - 9,999 / Piece
  • Min.Order Quantity: 100 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Port: Shenzhen
  • Payment Terms: L/C,D/A,D/P,T/T
  • Product Detail

    Product Details
    Model Number:OHEM12864-13B
    Brand Name:HEM
    Origin:China (mainland)
    Key Specifications/Special Features:
    0.96″ blue white 128×64 PMOLED display

            ●0.96″ 128 x 64 pixel
            ●Interface: SPI, I2C
            ●3.3-5V logic and power
            ●Drive IC: SSD1306
            ●View area: 23.744mm x 12.864mm
    Size: 0.96 inch
    Resolution: 128 x64
    Driving voltage: 2.8-3.3 V (with automatic booster)
    Driver IC: SSD1306
    Support interface: 8 bits parallel, 3/4 line SPI, I2C
    Color: white
    Light features: full angle, high contrast, low power consumption, the sun is visible
    OLED advantages
          ●Wide operating temperature range (solid-state devices with electro-optical properties that are independent of temperature)
          ●Ideal for video with rapid switching times (μs)
          ●High contrast (>2000:1)
          ●Thin (no backlight required)
          ●Uniform brightness
          ●Wide viewing angles (-180°) with no gray inversion
          ●Low power consumption
